4.3.2 Measurements for antifouling paint area
The measurements indicate the upper limit of the antifouling paint, not the true waterline of the boat.
Figure 1. Cross 60 Cabin
antifouling paint area
| Position | Description | mm (in) |
|---|---|---|
| 1 | At stern: directly up from chine | 130 mm (5.1") |
| 3 | At bow: down from chine along the bow | 250 mm (9.8") |
